Installing OpenBSD 7.4 was pretty simple. I followed the OpenBSD installation guide and used dd on a Linux box to write install74.img to a USB stick. Don’t use the .iso, it doesn’t boot. Then I booted off the USB stick. (You don’t have to disable UEFI.) I used a standard layout
At the time I wondered if I should install all the packages or not. I decided that maintenance would be simpler if I just went for everything, so I added all the packages including X. That turned out to be the right decision.
I used a relatively standard partitioning scheme, although I think I bumped up a few of the sizes. I probably should have bumped up X11R6 more, right now it’s at 41%:
/dev/sd0a 986M /
/dev/sd0l 295G /home
/dev/sd0d 291M /tmp
/dev/sd0f 5.8G /usr
/dev/sd0g 986M /usr/X11R6
/dev/sd0h 19.4G /usr/local
/dev/sd0k 5.8G /usr/obj
/dev/sd0j 2.9G /usr/src
/dev/sd0e 34.4G /var
Set up doas
After installing, I set up doas ‘cause I like seatbelts:
$ su
# vi /etc/doas.conf
permit persist andrewmemory as root
permit persist keepenv root as root
Install patches and packages
After that I installed patches:
$ doas syspatch
$ doas shutdown -r now
Next I installed a few useful packages:
$ doas pkg_add -i emacs mutt firefox wget
I picked the -no_x11 version for emacs, and the normal (not gpge, not sasl, not slang) version for mutt. I’m not going to be mailing to the world from this box, just looking at local emails. I also installed Firefox, which turned out to be another good idea. It’s a lot easier to search for doc on the firewall box itself than to ssh in.
Set up mfs for /tmp
Finally, I’m paranoid about wearing out my SSD, so I set up /tmp to be mfs in /etc/fstab using the useful instructions from Solene Rapenne:
$ doas vi /etc/fstab
#f1ea06b71e2dca43.d /tmp ffs rw,nodev,nosuid 1 2
swap /tmp mfs rw,nodev,nosuid,-s=300m 0 0
… and I had to boot to single-user mode to fix up permissions for /tmp:
$ doas umount /tmp
$ doas chmod 1777 /tmp
$ doas mount /tmp
Apparently tmpfs has been removed because it’s not supported, so mfs it is. I’ve got plenty of RAM for a /tmp file system, but I have delusions of putting most of /var in its own mfs file system, so I restricted /tmp to 300M.
Once that was done, I could log into a few other machines on my network to establish fingerprints for them. I also tested X by running startx, and then firefox, and it worked.
There were some noisy beeps
By default, OpenBSD rings the bell when you mistype certain things. That was annoying other people in the house, so I had to shut those up. That took two things. In ~/.login I added:
/sbin/wsconsctl keyboard.bell.volume=0
Then, I created ~/.xsession and added:
/usr/X11R6/bin/xset b off
This post is part of a series on [setting up an OpenBSD 7.4 firewall device](/blog/2023-10-15 23:45:00 GMT-7-setting-up-an-openbsd-7-4-firewall-device).
